Installation Guide for

MAX 1500 PRO/2200 PRO/f18 PRO

Slide Gate Operators

www.max.us.com

4009963

Residential/Commercial

Brushless DC Slide Gate Operators

Made in USA

CONFORMS TO UL STD 325

MAX 1500 PRO/2200 PRO UL CLASS - I, II, III, IV

MAX F18 PRO UL CLASS - III, IV ONLY

CERTIFIED TO CAN/CSA STD

C22.2 NO. 247

SAFETY SENSORS REQUIRED

CONFORMS TO UL STD 325

MATRIX III

Version 7a

Main Page

Questions and Answers

R
reginathompsonAug 22, 2025
Why is the “BATTERY IN ERROR” LED on my Max 2200 PRO on?
- R
  Roy ReedAug 22, 2025
  The “BATTERY IN ERROR” LED might be on for several reasons. First, ensure the “BATTERY Plug” is properly inserted into the “BATTERY IN” port. If AC power is lost, the operator switches to battery backup mode; check if the Toroid box AC POWER ON/OFF SWITCH is ON. If the battery is very low, check if the AC power ON/OFF switch is ON and verify AC power. If the BATTERY TEST fails and the “REPLACE BATTERY” LED is ON, the battery needs replacement. Also, ensure the battery is plugged into the BATTERY INPUT port.
J
Jonathan HoodNov 5, 2025
What to do if Max Gate Opener beeps but does not open?
- B
  brenda23Nov 6, 2025
  If the Max Gate Opener beeps but doesn't open or close, start by checking the GATE SHUTOFF switch to ensure it's OFF. Turn the switch ON then OFF again. Also, make sure the GATE DISABLE LED is OFF. Verify that the OPEN and CLOSE Limits have been learned. See if the GATE SPEED rotary dial is set to MAX. Confirm the gate isn't too heavy for the operator. Check if the "BATTERY IN USE" LED is ON, as this indicates battery backup mode with a low battery. Ensure the "Mode 1" switches are correctly set for operator mode. See if the “Gate in Motion” Alarm feature is ON and the “Mode 0” switches are set correctly. Check if the Power LEDs are ON on both Matrix III and Toroid box and if the “LINK ON” LED is ON. Also, verify the PRIMARY GATE "open RIGHT / open LEFT" switch is set properly. Ensure the ...
