Max DPG200 User Manual

Use one screw to hold Button body on
fence post.
Trim plastic tubes to match post depth
and insert.
Check both sides are unlocked. Hold the
Latch in place and test the Button works
the Latch.
All good? Completely mount Latch and
Button.
Not working? See Troubleshooting below.
Sit Striker in Latch and mark the Striker’s
centre on gate. Drill pilot holes and mount.
Test the locking and unlocking of the Latch
and Button.
Protrudes
7mm
Protrudes
13mm
13mm
7mm
Maintenance
• Inspect Latch annually or more frequently if the gate is used often.
• Only lubricate with powdered graphite lubricant. No petroleum-based lubricants, oils etc.
• Keep Latch free of contaminants
TROUBLESHO OT ING
If it doesn’t lock, rotate Lock Spindle 180°.
1. Remove keys.
2. Remove Latch off post.
3. Hold the Key, rotate Lock Spindle 180°.
4. Remount Latch, careful not to turn Lock
or Spindle.
Continued
CENTERLINE
OF LATCH
3/4"
SPINDLE
THRU
HOLE
GATE
FRAME
3/4"
FIG. 1
Spindle
12mm
Screw
30mm
Screw
Cut 11-13mm
Longer than Gate Post
Spindle Tube
MUST be fitted
Spindle Tube to be
11 to 13mm longer
than Gate Post
Spindle
INSIDE
LATCH
OUTSIDE
LATCH
CENTERLINE
OF LATCH
3/4"
SPINDLE
THRU
HOLE
GATE
FRAME
3/4"
FIG. 1
Spindle
12mm
Screw
30mm
Screw
Cut 11-13mm
Longer than Gate Post
Spindle Tube
MUST be fitted
Spindle Tube to be
11 to 13mm longer
than Gate Post
Spindle
INSIDE
LATCH
OUTSIDE
LATCH
To protect the
Latch from slam
damage add a
Gate Stop.
Lock
Spindle
Button
Spindle
Trim Spindles
CENTERLINE
OF LATCH
3/4"
SPINDLE
THRU
HOLE
GATE
FRAME
3/4"
FIG. 1
Spindle
12mm Screw
30mm
Screw
Cut 11-13mm
Longer than Gate Post
Spindle Tube
MUST be fitted
Spindle Tube to be
11 to 13mm longer
than Gate Post
Spindle
INSIDE LATCH
OUTSIDE LATCH
Button
POST (mm) TRIM MARK
50 2
75 4
90 5
100 6
125 no trim
Trim both Spindles using the trim
marks.
2
4
5
6
CENTERLINE
OF LATCH
3/4"
SPINDLE
THRU
HOLE
GATE
FRAME
3/4"
FIG. 1
Spindle
12mm
Screw
30mm
Screw
Cut 11-13mm
Longer than Gate Post
Spindle Tube
MUST be fitted
Spindle Tube to be
11 to 13mm longer
than Gate Post
Spindle
INSIDE
LATCH
OUTSIDE
LATCH
2
4
5
6
70
16
16
16
