SPECIFICATIONS
MECHANICAL
Housing
Self Extinguishable ABS Plastic
Dimensions (Largura x Altura x Fundo)
321 x 286 x 90 mm
Weight
1,6 Kg
ENVIRONMENTAL
Operating Temperature
-5ºC~45ºC (recommended 5ºC to 35ºC)
Rekative Humidity
5% a 95% without condensing
Protection Class
IP 40
ELECTRICAL
Primary Supply
Switched Supply 100-240V AC 50-60 Hz 1,5A
Backup Supply
2 x 12V Lead-Acid Bateries (up to 7,2 Ah)
Primary Supply Fuse
T 4 A L 250V 5X20
Backup Supply Fuse
24V DC 1.3 Amp resettable
Siren Output protection
300 mA Resettable Fuse
Aux Output protection
300 mA Resettable Fuse
Max. current draw per zone
57 mA (number of detectors per zone varies according
to their power consumption)
Baterie time (AC Power missing)
minimum 72 hours (with bateries 12V 7 Ah)
Endurance max. Internal Battery
25 mOhm
Factory Default Setting
Pre-Alarm timer (1-1)
60 seconds (OFF/ON/ON/OFF)
Zone Type (all zones) (menu 1-2)
Automatic (“Fault” Led On)
Alarm Relay (all zones) (menu 1-3)
Active (“Alarm” Led On)
Fault Relay (all Zones) (menu 1-4)
Active (“Fault Led On)
Sounder 1 Timer (menu 2-1)
5 minutes
Sounder 2 Timer (menu 2-2)
5 minutes
Supply Fault Timer (menu 2-3)
60 seconds
Confirmation Zones (menu 2-4)
All zones disabled
Sounder 1 output zones (menu 3-2)
All Zones
Sounder 2 output zones(menu 3-3)
All Zones
Programming Code (menu 4-1)
1 2 3 4
