A. Before You Begin
A-3 Understanding Your Child Restraint
Front View
A. Carry Handle
B. Headrest
C. Harness Covers
D. Infant Insert
E. Buckle Cover
F. Harness Release
Button
G. Harness
Tightening
Strap
H. Carry Handle
Adjustment Levers
I. Rear-Facing Belt
Path
(when used without
the base)
J. Removable Base
A.
B.
C.
D.
E.
F.
G.
H.
I.
J.
Back View
K.
L.
N.
M.
P.
O.
K. Canopy
Attachments
L. Canopy
M. Instruction
Manual Storage
(behind rubber trim)
N. Base Release Lever
O. Base Recline Lever
P. Level to Ground
Lines
(when used without
the base)
Q. Upper Harness
Slots
R. Harness Straps
S. Chest Clip
T. Buckle Tongue
U. Buckle
V. Lower Harness
Slots
W. Buckle Strap
X. Buckle Strap Slots
Harness System Detail
PUSH
Q.
R.
C.
S.
T.
U.
V.
W.
X.
