Maxim RMT55H - 3.3 Transmission Parts Breakdown

RMT55H
20195 South Diamond Lake Road, STE 100
Rogers, MN 55374
800.621-2789
19
Ref.
Qty
Part #
Description
1
1
130761
SLASHER TINE SET (HD)
2
1
359341
BRACKET,LOW B/GUARD-PAINT
3
3
87373
NUT, CLIP, 1/4-20, 0025-015, BLACK
4
1
359343
BRACKET,UPPER B/GUARD-PAINT
5
2
336678
BRACE. HANDLE BAR - PAINT
6
3
80027
BOLT,HHCS,1/4-20 X 1/2,GR5,ZINC
7
1
MX-130694
R.H. HANDLE ASSY -PAINT
7.1
1
313786
HANDLE GRIP, 1
7.2
1
87372
POST, BINDING, 0.25 X 1.25, ZINC
7.3
1
87425
BOLT, TRUSS, #10-24 X 5/16, ZINC
7.6
1
336683-SD
CLUTCH LEVER – PAINT, W/DECAL
7.7
1
130688-SD
TUBE, HANDLE, TILLER, W/DECAL
8
1
461469
PIN, DEPTH BAR ADJ.
9
1
MX-130695
L.H. HANDLE - PAINT
9.2
1
313786
HANDLE GRIP, 1
9.3
1
130688-SD
TUBE, HANDLE, TILLER,
10.1
1
130683
CROSS BRACE - PAINT (RMT55H)
10.2
1
336919
DECAL, HANDLE BRACE, COMMERCIAL
12 1
130733-
RMT55H
GUARD, BELT, W/DECALS
13.1 1 MX-
132183
HONDA ENGINE, 5.5 H.P. HORIZ.
SHAFT
13.2
1
104078
MUFFLER DEFLECTOR
13.3
1
162067
BELT GUIDE - PAINT
13.6
2
87437
8 X 1/4 FLG HEAD SCREW AB
13.7
2
80196
5/16 LOCK WASHER - ZINC
13.8
2
86667
BOLT, HHCS,5/16-24 X 3/4,GR5,ZINC
14
1
MX-162045
ASSY, YOKE
14.1
1
162033
MOUNT-YOKE REAR WHEELS
14.2
2
162065
WHEEL, 10" X 1.75" (H/D)
14.3
1
461468
PIN, COTTER, 7/64 X 1.00, ZINC
14.4
1
461467
PIN-L-1/2 X4 Zn-CLR
14.5
5
80207
WASHER, FLAT, 1/2 SAE, ZINC
14.6
1
359362
SPRING, 0.055 WDIA, 0.579 ID, 1.575
14.7
2
86453
CAP, PUSH, 1/2 ID, ZINC
15
1
500003
R. H. FRAME RAIL
17
1
130400
TRANSMISSION, COMPLETE PAINT
18
1
162069
IDLER SHAFT, TILLER
19
1
338009
IDLER PULLEY, 2-3/4" X 3/8"
Ref.
Qty
Part #
Description
20
2
359335
SPACER, TRANS. -FORM<7/8">
21
1
359325
LEVER, IDLER - CUT/PUNCH
22
2
130701
HITCH CASTING
23
1
336686
DEPTH BAR - PAINT
24 1 87433
SPRING, .055 WDIA, 0.75 ID, 1.5-0.35
LENGTH
25
3
87422
3/8-24 NYLOCK NUT
26
1
87270
3/8-24 HEX NUT
27
1
336671
PULLEY, 9" X 5/8"
28
1
87269
3/16 X 3/4 WOODRUFF KEYK9N
29
3
87268
5/16-18 X 5/16 SETSCREW ZN
30
1
271686
2 X 3/4 C/SHAFT PULLEY
31
1
86615
KEY-SQUARE 3/16 X 1-BR
32
8
80205
5/16 SAE FLAT WASHER - ZINC
33
11
86101
5/16 NYLON LOCK NUT
34 5 80045
BOLT, HHCS, 5/16-18 X 2 3/4, GR5,
ZINC
35
1
87282
BOLT,HHCS,5/16-18 X 2.25,GR5,ZINC
36
4
80039
5/16-18 X 1-3/4 HEX SCREW GR 5-
37
1
272201
BELT, 4L51
38.1
4
80031
1/4-20 X 1-1/2 HEX SCREW GR 5-ZINC
38.2
6
85128
1/4" NYLON LOCK NUT
38.3
1
87416
SPRING, EXTENSION
38.4
1
162041
CLUTCH CABLE ASSEMBLY
38.5
2
87274
5/16-18 X 3 3/4 CAP SCREW
38.6
4
80205
5/16 SAE FLAT WASHER - ZINC
38.7
4
86101
5/16 NYLON LOCK NUT
38.9
2
87374
P-CLIP, 3/8 X 9/16, GAL
38.10
4
461466
PIN, CLEVIS, 3/8, 2-1/4, ZINC
38.11
4
461468
PIN, COTTER, 7/64 X 1.00, ZINC
38.12
2
86115
5/16-18 X 1-1/4 HEX SCREW GR 5-ZINC
38.15
1
790471
HOLDER, MANUAL, SMALL
38.18
2
85015
BOLT, HEX, 1/4-20 X 2, GR 5, ZINC
38.19
1
80193
¼-20 x ½ THRD CUT HEX - ZINC
39
1
80037
5/16-18 X 3/4 HEX SCREW GR 5-ZINC
44
1
80212
1/4 USS FLAT WASHER - ZINC
46
1
500002
L.H. FRAME RAIL
47
1
359853
ENGINE GUARD
48
2
313786
HANDLE GRIP, 1
49
1
80206
WASHER, SAE 3/8 ZINC
