A
d
e
C
f
B
44
FIG. 7
FIG. 8
3
TH
STEP: TURNING ON
• Connect the supply cable to a 220V plug provided with
earth. Three red lights appear on display “e”.
• For the vacuum cleaner function: press push button “B” and
ad just the power by means of keys +/-.
• For the steam function: press push button “A”, after
about 5 minutes pilot light “d” lights up and the
device reaches the optimum working temperature and
pressure. The steam must be adjusted by means of the
knob (fig.7
The temperature remains displayed on the display. Once the
other functions are selected, the display shows them about
5 seconds.
NOTES: when pilot light “f” signalling that the water is finished
is on, the flashing writing “H2o” appears on the display and in
the meantime the steam delivery is stopped. In this case fill the
tank with water. (step 2).
• For the iron / carpet cleaner function: press push button
“C”, the corresponding pilot light lights up and the writing
“ACC” appears on the display.
4
TH
STEP: HOSE CONNECTION
• To connect the hose, move upwards the door covering the
plug (fig.8), insert the plug and close the door by making
sure the pawl is into its proper seat.
LIST OF THE PANELS FUNCTIONS
A. Push button to turn the boiler on
B. Push button to start and adjust the
motor (+/-)
C. Push button to start the iron / carpet cleaner
d. Pilot light signalling the steam is ready
e. Display
f. Pilot light signalling the water is finished
