MAXIMATOR GPLV 2 - 6 Technical Data

Technical Data
Air Amplifiers Revision 11.2011
21
6 Technical Data
Technical Data GPLV 2 SPLV 2 MPLV 2 SPLV 3 MPLV 4 GPLV 5
Pressure ratio 1:2 1:2 1:2 1:3,2 1:4 1:5
Air drive pressure in bar 1-10 1-10 1-10 1-10 2-10 1-10
max. operating pressure in bar 20 20 20 32 40 60
max. noise level in dB 79 79 79 79 79 79
max. operating temperature in °C 60 60 60 60 60 60
Port for air drive pressure G 3/4“ G 1/2“ G 3/8“ G 1/2“ G 3/8“ G 1/2“
Port for pressure inlet G 1/2“ G 1/2“ G 3/8“ G 1/2“ G 3/8“ G 3/8“
Port for pressure outlet G 1/2“ G 1/2“ G 3/8“ G 1/2“ G 1/2“ G 3/8“
Weight 20.5 16.0 3.3 8.5 2.2 16.0
