NOTE: During cold weather or in cold temperature environments,
store the compressor in a warm area when not in use. This will
improve performance and reduce starting problems.
NOTE: The compressor must be placed on a flat surface to ensure
proper drainage of the moisture in the tank.
ASSEMBLY INSTRUCTIONS
3. Locate the compressor near a
grounded electrical outlet (2)
(FIG. C).
4. Connect an air hose (1) to the air line
outlet (2). Then connect the air hose
to an air tool (3) e.g. air-powered
spray gun (FIG. D).
