26
model no. 058-9317-8 | contact us 1-888-670-6682
EXPLODED VIEW AND PARTS LIST
No. Kit Number Part Number Description Qty.
1 6 Screw, M6 x 1 x 35 mm
4
2 4,6,9
Lock Washer, M6 12
3 6 E100284
Head, Cylinder 1
4 1 & 6
Screw, HFH M3 x 0.4 x 5 mm 2
5 1 & 6
Washer, Lock M3 1
6 1 & 6
Retainer, Outlet Valve 1
7 1 & 6
Valve, Outlet 1
8 1, 6, 10
Gasket, O-ring, Cylinder 1
9 1 & 6
Valve Plate 1
10 1, 6, 10
Gasket, O-ring, Head 1
11 1 & 6
Valve Inlet 1
12 1 & 6
Retainer, Inlet Valve 1
13 2 & 6
Cylinder 1
14 6 E105192
Capacitor, Running (Motor-60μF/250VAC) Bkt Mt. 1
15 6 E105191
Capacitor, Starting (Motor-150μF/125VAC) Bkt Mt. 1
16 6
Screw, Pan Head M6 x 1.0 x 10 mm 2
17 6
Nut, M8 x 1.25 2
18 6 E105018
Bracket, Capacitor Extender 1
19 6
Motor/Pump F2 1
20 3 & 6
Assy, Eccentric and Bearing 6203ZC3 1
21 3 & 6
Screw, SHCS M6 X 1 X 35 mm 1
22 2 & 6
Nut, M5 X 0.8 1
23 2 & 6
Screw, SHCS M5 X 0.8 X 25 mm 1
24 2 & 6
Rod, Connector 1
25 2 & 6
Ring, Piston 1
26 2 & 6
Cap, Piston 1
27 2 & 6
Screw, SHC M5 X 0.8 X 15 mm 1
28 6 E100297
Fan, Cooling 1
29 6 & 11
Washer, Flat M6 1
30 6 & 11
Screw, SHC M6 x 1.0 x 16 mm (Left Hand Thread) 1
31
M6 x 12 6
32 6
Motor/Pump Assembly F2B2 (Right Hand Exhaust) 1
33 9
Shroud F2 Left 1
34 9
Shroud F2 Right 1
35 9
Screw #8 4
36 E104827
Elbow, Outlet, 135 Degree 1/2” MNPT X 3/8” Flare 1
37
Screw, HFH M6 x 1.0 x 12 mm 6
38 5
Nut, Flare, 3/8” 1
NOTE: ANY PART NUMBER FIELD WITHOUT A NUMBER LISTED IS NOT AVAILABLE.
