EXPLODED VIEW AND PARTS LIST
No. Kit Number Part Number Description Qty.
39 5
Tube, Exhaust 3/8” Flared and Finned w/ Flared Nut 1
40 5
Nut, Comp, 3/8” 1
41 5
Ferrule, 3/8” 1
42 E101362
Valve, Check, 90 Degrees Left 1
43 8
Ferrule, 1/4” 1
44 8
Nut, Comp, 1/4” 1
45 8
Tube, Relief, 1/4” Copper 1
46
Nut, M8 x 1.25 6
47
Washer, Flat 8 x 19 mm 4
48
Screw, SHC M8 x 1.25 x 16 mm (ZDC Plate) 4
49
Screw, SHC M6 X 1.0 X 16 mm 2
50
Washer, Flat M6 X 12 mm OD 6
51
Assy, Tank Weldment 15 Gallon Vertical 1
52
Bolt, HH M8 x 1.25 x 30 mm 2
53 E100240
Isolator, Foot (60 mm Dia X 28 mm Tall) 2
54
Washer, Flat M8 x 24 mm OD X 2 mm (ZDC plate) 2
55
Washer Lock M8 X 14.8 OD X 2 mm Thick 2
56 E101717
Valve, Drain, 1/4 Turn 1
57 4
Bolt, Shoulder M10 x 1.5 x 55 (Shoulder to 39 mm) 2
58 4
Wheel, 7 x 2.2” Mag BLK 2
59 4
Washer, Flat M10 2
60 4
Nut, Hex Lock Nylon Inserted M10 x 1.5 (Bright Zinc) 2
61 E101790
Cord, Power, 14/3 AWG, Length 6’ Type ST 1
62 E100853
Nipple, 1/4” MNPT x 35 mm 1
63 E106272
Pressure Switch BTM Centre Base NPT 1
64 E100724
Nipple, 1/4” MNPT x 50 mm 1
65 E105755
Regulator, 3-Port, 1/4” NPT
66 E100307
Quick Connect, Steel 1
67 E104074
Bezel, Gauge Ident, Tool (Fits 2”/50 mm Gage Hsng) 1
68 E106109
Gauge 50 mm 350PSI No R/L 1/4 NPT 2
69 E104075
Bezel, Gauge Ident, Tank (Fits 2”/50 mm Gage Hsng) 1
70 E105624
Valve, Safety 1
71 7
Cap, Air Filter 1
72 7 E100435
Element, Air Filter 1
73 7
Base, Air Filter 1
74
Screw, HFH Serrated, M8 x 1.25 x 20 mm Self Tap 4
75 E103485
Handle, 20gal Vert. 1
76 E101490
Grip, Handle Rubber 1
To Next Page
