EXPLODED VIEW AND PARTS LIST
Kit Name Kit Number Order Number Component Reference #
Kit, Valve Plate 1 E103497 4-12
Kit, Piston 2 E103495 12, 22-27
Kit, Eccentric 3 E104441 20-21
Kit, Wheel (Replaces One Wheel Assy.) 4 E106270 57-60
Kit, Finned Aluminum 3/8"Outlet Tube 5 E106979 38-41
Kit, F2B2 Motor/Pump Assy (Right Hand Exhaust) 6 E104279 1 - 30,32
Kit, Air Filter 7 E100794 71-73
Kit, Pressure Relief Tube 1/4" Copper 8 E104834 43-45
Kit, Shroud Replacement 9 E106985 33-35
Kit, O-Ring 10 E105845 8 & 10
