CYCLONE BAGLESS VACUUM CLEANER
SL-008
1), COMPONENTS LIST FOR SL-008
1, ON/OFF SWITCH PEDAL
2, HANDLE
3, CORD REWINDING PEDAL
4,POWER REGULATINGROLLING
5.FRONT COVER
6.HOSE SOCKET
7.COMBI NOZZLE
8.TUBES
9.HOSE
10.FLOOR BRUSH
11.REAR WHEEL
12.FILTER
13.DUST CONTAINER
14.DUST CONTAINER BUTTON
2)OPERATING MODE:
1. Connect the hose accessories:
press the adaptors at both side of the hose end, then insert the
hose into the hose socket.
2.Connect the metal tube to the curved end of hose.
3.Connect the different nozzle tools/floor brush to the tube for
different cleaning purposes. The floor brush has two positions,
one for soft/textile surfaces. The combined nozzle is for narrow
