Maxon OD808 User Manual

14
SAMPLE SETTING
D&SⅡ No.1 (for single-coil pickup)
Setting for solid boost sound with your amplifierʼs
original character preserved.
D&SⅡ No.4
High gain type distortion to boost amplifierʼs drive.
Adjust the balance between amplifierʼs gain volume
and D&SⅡʼs DISTORTION.
D&SⅡ No.2 (for humbucking pickup)
Setting for solid boost sound with your amplifierʼs
original character preserved.
D&SⅡ No.3
Easy-to-control setting to simulate tube amplifier dis-
tortion.
D&SⅡ No.5
Fat and heavy distortion particular to D&SⅡ. TONE
can be adjusted for fuzz-like sound.

Maxon OD808 Specifications

General

Type	Overdrive
Controls	Drive, Tone, Level
Power Supply	9V DC
Weight	580 g
Technology	Analog
Input Impedance	500 kOhms
Output Impedance	10 kOhms
Inputs	1 x 1/4"
Outputs	1 x 1/4"
Power Source	9V Battery or AC Adapter
Current Draw	6mA at 9V
