SAMPLE SETTING
CP101 No.1
Setting for bass guitar and also for MTR. Attack tone
in slapping can be adjusted by SUSTAIN volume.
CP101 No.4
Setting for balanced attack of chord stroke both in
drive and clean sound.
CP101 No.2
Setting for even attack of fingerpicking and arpeggio
to get balanced tone. Also ideal for MTR.
CP101 No.3
Setting for clean tone solo.
It makes clean + sustain tone that is characteristic of
compressor.
CP101 No.5
For smooth lead sound by adding CP101ʼs sustain to
amplifierʼs drive.
CP101 No.6
Setting to even out the chord riff attack in drive
sound and arpeggio in clean sound.

Maxon OD808 Specifications

General

Type	Overdrive
Controls	Drive, Tone, Level
Power Supply	9V DC
Weight	580 g
Technology	Analog
Input Impedance	500 kOhms
Output Impedance	10 kOhms
Inputs	1 x 1/4"
Outputs	1 x 1/4"
Power Source	9V Battery or AC Adapter
Current Draw	6mA at 9V
