CP9Pro
+
Compressor/Limiter
FEATURES AND CONTROLS
●CP9Pro+ by use of high-quality VCA (voltage controlled amplifier) and RMS
(root-mean-square) sensor, provides natural attack response with low noise.
●CP9Pro+ uses a DC to DC voltage converter to bump 9V up to 18V. PT9Pro+
provides wide dynamic range and sufficient head room against distortion.
●Compression/Limit level response to picking dynamics is easily viewable with
Threshold LED.
①IN (input jack)
Input jack to connect to the output of guitar,
other effects or related equipment. The
product automatically turns on when a plug
is inserted into this jack. When not in use,
disconnect plug from input jack to preserve
battery life.
②OUT (output jack)
Output jack to connect to the input of
amplifier or other effects.
③THRESHOLD (threshold level control knob)
Controls threshold level of compression.
(Fig. 1) When an input signal is above the
THRESHOLD level, compression will be
carried out in the manner defined by the
setting of the RATIO control. (Fig. 2)
Compression starts from a low level when
this control is turned clockwise. So turn the
output level up by the GAIN control since the
output level becomes also low. (Fig. 3)
④RATIO (ratio control knob)
Controls compression ratio. Turn RATIO
control knob clockwise to increase
