MaxPower Sunbridge 2000 - Page 15

13
Charging current
(if PV normal)
Charging current=50A
Main CPU
version
checking
Main CPU version 00000.00
Battery voltage
Battery voltage=27.0V
Secondary CPU
version
checking
Secondary CPU version 00000.08
Output frequency
Output frequency=50Hz
Operating Mode Description
Operation mode
Description
LCD display
Standby mode
Note:
*Standby mode: The inverter is
not turned on yet but at this
time, the inverter can charge
battery with AC bypass output.
Utility input bypass to
output, charger
available, LCD backlight
is off
Charging by utility and PV energy.
Charging by utility.
Charging by PV energy.
Line Mode
The unit will provide
output power from the
mains. It will also
charge the battery at
line mode.
Charging by utility and PV energy.
Charging by PV energy.
Charging by utility.
