Maxray Folding Solar Panel - Solar Panel Components and Regulator; Solar Panel Components; Regulator Components

AFTER SALES SUPPORT
support@maxray.com.au
V 2.1
3
1
2
3
4
5
6
1
2
5
7
8
6
9
3
Components
Solar Panel Regulator
2 x Folding Mono-Crystalline
silicon solar panels. Heavy duty
anodised aluminium frame.
Tempered Glass coating.
Heavy duty ABS handle.
Heavy duty steel safety
fasteners.
Heavy duty aluminium folding
support legs.
Automatic SMART solar charge
controller with LED indicators.
5m cable + Anderson Plug
to Alligator Clip adaptor.
Hinges.
Solar panel junction box.
Connecting cable
between left and right
solar panel.
Power IN indicator
Power OUT indicator
Battery capacity indicator
Solar panel connection
Battery connection
12v direct connection
1
6
2
1
2
7
3
3
8
4
4
9
5
5
6
4
