Please Note:
Mark the polarity of the existing speaker wires before disconnecting battery.
1. After removing the old radio and mounting
sleeve, insert supplied mounting sleeve
into opening.
2. Bend the tabs on the mounting sleeve to
keep the mounting sleeve firmly in place.
3. Attach the wires from the unit to the
existing wires. See wiring connections
diagram. Insert radio into dashboard
then apply the trim frame to the
outside of radio.
DIN Front Mount
Installation
WARNING!
Disconnect negative battery terminal from battery before starting installation.
Consult the vehicle owner’s manual for proper instructions.
3
After Sales Support
UK/N.IRELAND HELPLINE N
O
:
REP.IRELAND HELPLINE N
O
:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
enquiries@quesh.co.uk
Supplied Parts
2 Keys
1 Faceplate Case (not shown)
1 1/8” Stereo Cable
1 Remote control
