MAXTEK 66050 - Setting Up Both Screens

Setup
DC in
DC in
AV out
AV in
AUX Lead
Or
Mains Adaptor
In-Car
Adaptor
Chosen Primary
Screen
Chosen Secondary
Screen
Setting up both screens
Both screens are capable of sharing video content with each other.
Please follow the diagram below to setup the secondany screen to
receive the output video feed from the chosen primary screen.
Select AV1 on the secondary screen to view the output by pressing
‘MODE’ on the remote.
8
After Sales Support
UK/N.IRELAND HELPLINE N
O
:
REP.IRELAND HELPLINE N
O
:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
enquiries@quesh.co.uk
Power Splitter
