Maxview Roam X - Get to know your Router

12
Front View
Mobile signal strength
indication LEDs
Mobile network
type LEDs
Mobile MAIN
Antenna Connection
Power Socket
Wi-Fi Antenna
Connector
Blutooth Antenna
Connection
Power
LED
Wan Ethernet
Port
Get to know your Router
Credential Router Sticker (Located on the reverse of the router).
SERIAL: XXXXXXXXXXX
IMEI: XXXXXXXXXXX
LAN MAC: XXXXXXXXXXX
WIFI SSID: RUTXXXXXX
PASSWORD: XXXXXXXX
BATCH No. xxxx
QR CODE
See page 14 for details.
Serial
Number
Password
Code
Wi-Fi
I.D
RUTX11 XXXXXXXX
SIM needle
WAN type LEDs
Reset
Button
LAN Ethernet
Ports
SIM
Holders
Wi-Fi Antenna
Connector
USB
Port
GNSS Attenna
Connector
Mobile AUX
Antenna Connection
Grounding
Screw
Back View
