Maxwell 25602 - Page 4

EN
User Manual
AC CURRENT
Range Resolution Accuracy (%)
40A 0.01A ± (3.0% + 10 digit)
400A 0.1A ± (2.5% + 8 digit)
1000A 1A ± (3.0% + 10 digit)
DC VOLTAGE
Range Resolution Accuracy (%)
400mV 0.1mV
± (0.5% + 4 digit)
4V 0.001V
40V 0,01V
400V 0.1V
1000V 1V ± (1.0% + 6 digit)
Input Impedance: 10MΩ
MAX. INPUT VOLTAGE: 1000V DC OR MAX. AC VALUE
AC VOLTAGE
Range Resolution Accuracy (%)
400mV 0.1mV ± (1.6% + 8 digit)
4V 0.001V
± (0.8% + 10 digit)40V 0,01V
400V 0.1V
750V 1V ± (1.0% + 10 digit)
Input Impedance: 10MΩ
Max. Input Voltage: 1000V DC or AC maximum value
Frequency Range: below 400V: 40-400Hz, above 400V: 40-200Hz
RESISTANCE
Range Resolution Accuracy (%)
400Ω 0.1Ω ± (0.8% + 5 digit)
4kΩ 1Ω
± (0.8% + 4digit)
40kΩ 10Ω
400kΩ 100Ω
4MΩ 1kΩ
40MΩ 10kΩ ± (1.2% + 10 digit)
Overload Protection: 250V DC or AC maximum
