1.2 PRODUCT VARIATIONS
There are two options of above-deck arangements or
“topworks”, combined with four types of drives.
The types of topworks are:
VWC - vertical windlass with chainpipe
VWCLP - vertical windlass with chainpipe, low prole
Each of the above topworks is available as clockwise
or anticlockwise conguration (see description of
Denition of rotation in Section 2.1).
Beside friction clutch, which can be used for controlling
chain speed while free falling anchor, the windlasses
can also be equipped with an external band brake.
The types of drives are:
Electric DC drive (24V)
Electric AC drive (horizontal motor)
Hydraulic drive
The above deck components of the windlass can come
in several different materials / nishes:
Chrome over polished bronze
Bare polished bronze
Stainless steel
Titanium nitride coated bronze or stainless steel
Picture 1.1
VWC topworks
Picture 1.3
VWCLP topworks
Picture 1.4
Electric DC drive
Picture 1.5
Electric AC drive
5
Picture 1.6
Hydraulic drive
Picture 1.2
VW topworks
