MaxxPet 88267 - Page 6

6
3. LUMEN INSTELLEN TIJDENS HET OPENEN VAN DE DEUR (00~23)
(TIJDSBEREIK VAN HET OPENEN VAN DE DEUR: 00~11)
Houd de instelknop 1 seconde ingedrukt en laat vervolgens los, weergegeven
zoals op de afbeelding zal beginnen te knipperen zoals
weergegeven in de afbeelding, druk op de toenameknop of de afnameknop
om de lumen aan te passen (Nummer 0 betekent minimale lumen, zwakste licht.
Nummer 23 betekent maximale lumen, sterkste licht)
4. STEL DE TIJD IN WAAROP DE DEUR MOET WORDEN GESLOTEN (12~23)
Druk de instelknop gedurende 1 seconde in en laat hem dan los, weergegeven
zoals op de afbeelding zal beginnen te knipperen zoals
weergegeven in de afbeelding. Druk op de toenameknop of de afnameknop
om het uur aan te passen.
Druk de instelknop 1 seconde in en laat hem los. zal beginnen te knipperen
zoals weergegeven in de afbeelding. Druk op de toenameknop of
de afnameknop om de minuten aan te passen.
5. LUMEN INSTELLEN TIJDENS HET SLUITEN VAN DE DEUR (00~23)
(TIJDSBEREIK VAN HET SLUITEN VAN DE DEUR: 12~23)
Houd de instelknop 1 seconde ingedrukt en laat vervolgens los, weergegeven
zoals op de afbeelding zal beginnen te knipperen zoals
weergegeven in de afbeelding, druk op de toenameknop of de afnameknop
om de lumen aan te passen (Nummer 0 betekent minimale lumen, zwakste licht.
Nummer 23 betekent maximale lumen, sterkste licht)
2. Set the time to open the door(00~11)
Press the setting button for 1 second and release, displaying as shown
（OPEN UP TIME）,it will start to flash as shown in the figure ，press the increase button or the
decrease button to adjust the hour .
Press the setting button for 1 second and release,it will start to flash as shown in the figure ,
press the increase button or the decrease button to adjust the minutes .
3.Set Lumens while door opening (00~23) (time range of door opening: 00~11)
Press the setting button for 1 second then release, displaying as shown
（OPEN LIGHT SET 14）,it will start to flash as shown in the figure ，press the increase button or
the decrease button to adjust the Lumens.(Number 0 means minimum Lumens, weakest light.
Number 23 means maximum Lumens, strongest light)
4.Set the time to close the door(12~23)
Press the setting button for 1 second then release, displaying as shown
(CLOSE DOWM TIME）,it will start to flash as shown in the figure , press the increase button or the
decrease button to adjust the hour .
Press the setting button
for 1 second and release,it will start to flash as shown in the figure ，
press the increase button or the decrease button to adjust the minutes .
2. Set the time to open the door(00~11)
Press the setting button for 1 second and release, displaying as shown
（OPEN UP TIME）,it will start to flash as shown in the figure ，press the increase button or the
decrease button to adjust the hour .
Press the setting button for 1 second and release,it will start to flash as shown in the figure ,
press the increase button or the decrease button to adjust the minutes .
3.Set Lumens while door opening (00~23) (time range of door opening: 00~11)
Press the setting button for 1 second then release, displaying as shown
（OPEN LIGHT SET 14）,it will start to flash as shown in the figure ，press the increase button or
the decrease button to adjust the Lumens.(Number 0 means minimum Lumens, weakest light.
Number 23 means maximum Lumens, strongest light)
4.Set the time to close the door(12~23)
Press the setting button for 1 second then release, displaying as shown
(CLOSE DOWM TIME）,it will start to flash as shown in the figure , press the increase button or the
decrease button to adjust the hour .
Press the setting button
for 1 second and release,it will start to flash as shown in the figure ，
press the increase button or the decrease button to adjust the minutes .
