CAUTION:
This training device is to be used for its specic intended use only. If improperly used there is a risk of injury to the user. Read the
assembly and operating instructions carefully and observe all instructions and information. Keep children and pets well away from this
training device.
Overall View of the Device & Warnings
Fixing Materials
Cushion
Foam roller
Handles
Height adjustment fast pin
Part 12 – hexagon bolt M10x75 (4 pcs)
Part 13 – hexagon bolt M10x65 (2 pcs)
Part 19 – hexagon bolt M10x50 (2 pcs)
Part 14 – hexagon bolt M8x20 (4 pcs)
Part 17 – lock nut M10 (8 pcs)
Part 16 – washer Ø 8 (4 pcs)
Part 15 – washer Ø 10 (16 pcs)
