Scope of delivery
14
Part-No.
Name
QTY
Figure
A
Main frame
1
B
Rear foot
1
3
Back Pad
1
7
Flat washer Ø10
4
8
Lock Nut M10
2
9
Flat washer Ø8
6
10
Inner hexagon screw
M8x60
6
11
Inner hexagon screw
M10x70
2
