Carefully unpack all delivered parts. Have someone there to help you as some of the training device parts are
bulky and heavy. Check that all the parts and fixing materials (screws, nuts, etc.) have been delivered.
Assemble the parts carefully as any damages or defects occurring due to mistakes made at the time of
assembly are not covered by the warranty or guarantee. Therefore, read through the assembly instructions
carefully before you start assembling, follow each assembly step exactly as described and keep to the correct
sequence of assembly as instructed.
Assembly of the training device must be carried out thoroughly by adult persons only.
Assemble the training device in a location which is level, clean and clear of obstructions. 2 people are required
to carry out the assembly. Please be aware a possible risk of injury at the time of assembly and at each time of
using this device exists. For this reason, always be careful and thorough in your actions when assembling this
device.
Make sure that the parts necessary for each stage of assembly are only hand tightened together and only
tighten parts completely when all parts have been fitted together perfectly.
Training can only start when the training device has been fully assembled and all parts are screwed tightly.
Assembly step 1
Assembly
15
Part-No. 11
Inner hexagon screw M10x70
2 pieces
Part-No. 7
Flat washer Ø10
4 pieces
Part-No. 8
Lock Nut M10
2 pieces
A
B
7
7
8
11
