Part List
Part Description Type Qty
1 Main Frame 1
2 Incline frame 1
3 Upright post (L) 1
4 Upright post (R) 1
5 Console frame 1
6 Display frame 1
7 Motor installation panel 1
8 Fixed plate 2
9 Running deck 1410x650x21mm 1
10 Running belt 3360x580xt2.2mm 1
11 Front roller 1
12 Rear roller 1
13 Side rail 2
14 Side rail connector (L) 1
15 Side rail connector(R) 1
16 End cap 1
17 Front cover 1
18 Upper Motor cover 1
19 Upper console cover 1
20 Lower console cover 1
21 Display Rear cover 1
22 Screen plate 1
23 Console rear cover 1
24 Upright post cover (Outer Left) 1
25 Upright post cover (Inner Left) 1
26 Upright post cover (Inner Right) 1
27 Upright post cover (Outer Right) 1
28 PU handle bar 2
29 Motor 1
30 Incline motor 1
31 Inverter 1
32 Allen C.K.S. half thread screw M8x75x20 1
33 Motor belt 270PJ10 270PJ10 1
34 Safety key xed plate 1
35 Safety key press part 1
36 Safety key pulling part 1
37 Spring Ø11.8xØ0.8x24 1
38 Powder metallurgy sets Ø35xØ30xØ20x27 2
39 Filter 10A 1
40 Column cushion Ø30x30xM8x8 4
41 Cushion 80x54x40 4
42 Foot pad Ø74x86xM12 2
