12
6. CUR.(Cursor) button
The desired frequency can be directly entered using the cursor function
in normal mode. The desired frequency however should be in the
allocated frequency range of the band. To enter the frequency directly
using cursor function, follow the example:
1) Example of Frequency selection
Frequency desired is 145.4650 MHz on the VHF Band.
- Press the "BAND" button till the VHF FM Band is indicated, then
press “CUR” button. the first digit of the frequency display will start to
flash. Now press "▲ or ▼" button to set the value to " 1 ":
- Press the "CUR” button, the second digit of the frequency display
will start to flash. Now press "▲ or ▼" button to set the value to " 4 ":
- Continue this process for the remaining digits until you have entered
the desired frequency.
- Press “MO/SET” button after selection of Frequency.
NOTES : If you have selected a frequency which is above or below
the frequency range allowed, the unit will automatically go to
either the maximum or minimum frequency allowed per
band and the mode is also changed.
