Maycom FR-100 - Specifications; General Specifications; Receiver Section Specifications

14
1. GENERAL
FREQUENCY ------------------------ A BAND : 66MHz TO 88MHz
B BAND : 88MHz TO 108MHz
C BAND : 108MHz TO 136MHz
D BAND : 136MHz TO 174MHz
E BAND : 420MHz TO 470MHz
FREQUENCY GENERATION ---
PLL SYNTHESIZER
FREQUENCY STABILITY --------
+/- 15ppm
OPERATING TEMPERATURE --
-10℃ TO +55℃
POWER SOURCE ------------------ INT
: 4.5V
EXT : 4.5 TO 6.0V
MODULATION ----------------------- F3E, A3E
IMPEDANCE -------------------------
50 ohm
DIMENSIONS ------------------------
58(W) x 103(H) x 26.5(D)mm
WEIGHT -------------------------------
98.5g, W/O BATTERY
2. RECEIVER SECTION
CIRCUIT TYPE ---------------------- TRIPLE CONVERSION
SUPERHETERODYNE
IF FREQUENCY --------------------
1'st IF : 252.000MHz
2'nd IF: 10.7MHz
3’rd IF : 450KHz
SENSITIVITY ------------------------
FM : 0.5μV FOR 12dB SND
AM : 1μV for 10dB NQ
SELECTIVITY -----------------------
50dB Min.
S/N RATIO ----------------------------
40dB Min.
AUDIO OUTPUT @10%THD ----
150mW 8Ω, BTL
■ SPECIFICATION
MANUAL SIZE: 110 X 190 mm / MATERIAL: ART PAPER(W/O COATING)
MANUAL-USER(FR-100) / ERP CODE: 2190014 / English / Maycom Export Version
[2008.09.08] 8, 9, 11, 12 page edit version
