Installation and Operational Instructions for
ROBA
®
-brake-checker plus DC Type 028.600.2 (B.0286002.EN)
your reliable partner
27/03/2023 TF/GF
Page 3 of 14
Chr. Mayr GmbH + Co. KG
Eichenstraße 1, D-87665 Mauerstetten, Germany
Tel.: +49 8341 804-0, Fax: +49 8341 804-421
www.mayr.com, E-Mail: public.mayr@mayr.de
33
Safety and Guideline Signs
DANGER
Immediate and impending danger, which can
lead to severe physical injuries or to death.
CAUTION
Danger of injury to personnel and damage to
machines.
Guidelines on important points.
General Safety Guidelines
DANGER
Danger of death! Do not touch voltage-carrying
lines and components.
DANGER
Danger of burns when touching hot surfaces.
CAUTION
• Danger of device failures caused by short-
circuits and earth short-circuits at the
terminals
• Electronic devices cannot be guaranteed fail-
safe.
During the risk assessment required when designing the machine or
system, the dangers involved must be evaluated and removed by
taking appropriate protective measures.
To prevent injury or damage, only professionals and specialists
are allowed to work on the devices. They must be familiar with the
dimensioning, transport, installation, initial operation, maintenance
and disposal according to the relevant standards and regulations.
Before product installation and initial operation,
please read the Installation and Operational
Instructions carefully and observe the Safety
Regulations. Incorrect operation can cause injury
or damage.
General Safety Guidelines
Only carry out installation, maintenance and
repairs in a de-energised, disengaged
state and secure the system against inadvertent
switch-on.
Type tag
Type tag
1 Type name
2 Size/Type number
3 Article number
4 Serial number
5 Additional text
6 Overexcitation voltage/Holding voltage
7 QR code
8 No specification (internal use)
9 CE Identification
10 UL Identification
11 UKCA Identification
12 Symbol for "Observe instructions"
13 High voltage
