3
INSTALLATION REQUIREMENTS
Tools and Parts
Gather the required tools and parts before starting installation. The
parts supplied are in the washer drum.
Tools needed for connecting the water inlet hoses
■ Pliers (that open to 1
9
/16" [39.5 mm])
■ Flashlight (optional)
Tools needed for connecting the drain hose
■ Locking pliers (that open to 1
9
/16" [39.5 mm])
Tools needed for installation
■ Open end wrenches 14 mm and 13 mm
■ Level
■ Wood block
■ Ruler or measuring tape
Parts supplied
AB
F
G
C
DE
A. Drain hose form
B. Inlet hose (2)
C. Inlet hose washer (4)
D. Drain hose
E. Transport bolt hole plug (4)
F. Beaded strap
G. Hose clamp
