Parts of the washing machine
1. Detergent compartment - pre-wash
2. Detergent compartment - main wash
3. Fabric softener compartment
Detergent compartment
1. Detergent compartment
2. Main power switch
3. Programme panel
4. Type plate
5. Hatch - drainage pump
6. Drainage pump (behind hatch)
7. Washer door
8. Outer door (not all models)
5
4
2
3
1
6
7
8
1
2
3
