22 16022904 Rev. 0 ©2004 Maytag Appliances Company
Troubleshooting Procedures
WARNING
To avoid risk of electrical shock, personal injury or death, disconnect power to unit before servicing, unless testing
requires power.
Single Dryer Troubleshooting Guide
Dryer Drum
Will Not
Turn
Enter service mode
using the service
switch.
Clear the diagnostic codes.
Exit service mode.
Did a diagnostic code
appear?
Does 115 VAC appear
across the motor?
Replace the motor
Does the display
show Zero minutes?
Replace the door
switch.
Check wiring and
termination between
control board, motor
relay, door switch, motor
and thermal fuse.
Start a diagnostic cycle .
Does 115 VAC appear
across the motor?
Is the drum belt in the
proper position and not
damaged?
Position the belt
correctly or
replace the belt.
Let the motor and
thermal protector cool for
5 minutes.
Does the drum
turn?
Normal operation
See the single
dryer diagnostic
code guide.
Replace the
control board.
Yes
No
Yes
No
No
Yes
No Yes
No
Yes
No
To Next Page
