10. Thread the belt through the rear seat
as shown in the figure.
11. Place the flat tire in the luggage
compartment.
12. Thread the buckle through the wheel
as shown in the figure.
13. Thread the belt through the buckle
while pressing the tire to the seatback.
14. Pull the belt end to secure the flat tire.
In Case of an Emergency
Flat Tire
7-13
