Black plate (261,1)
MIN fill line
Automatic transaxle Fluid
(ATF)
í
qInspecting Automatic transaxle
Fluid Level
The autom atic transaxle fluid level should
be inspected regularly. Measure it as
described below.
The volume of fluid changes with
temperature. Fluid must be checked while
idling the engine without driving at
normal operating temperature.
1. Park on a level surfa ce and set the
parking brake firmly.
2. Start the engine and depress the brake
pedal.
3. Move the shift lever through all ranges
and set it at P.
WARNING
Make sure the brake pedal is applied
before shifting the shift lever:
Shifting the shift lever without first
depressing the brake pedal is
dangerous. The vehicle could move
suddenly and cause an accident.
4. With the engine still idling, pull out the
dipstick, wipe it clean, and put it back.
Maintenance and Care
Owner Maintenance
8-17
í
Some models.
Mazda2_8DB3-EC-13G_Edition4 Page261
Wednesday, June 4 2014 10:31 AM
Form No.8DB3-EC-13G
