CAUTION
To prevent damage to the rear
window let the wiper arm down
easily, do not let it slap down on the
rear window.
3. Pull down the blade rubber and slide it
out of the blade holder.
4. Remove the metal stiffeners from each
blade rubber and install them in the
new blade.
CAUTION
Do not bend or discard the stiffeners.
You need to use them again.
5. Carefully insert the new blade rubber.
Then inst all the blade assembly in the
reverse order of removal.
Maintenance and Care
Owner Maintenance
8-23
