Control Panel
í
Temperature control dial
A/C switch
Fan control dial
Mode selector dial
Air intake selector
Rear window defroster switch
Some models.
qControl Switches
Temperature control dial
Cold Hot
This dial controls temperature. Turn it
clockwise for hot and counterclockwise
for cold.
Fan control dial
This dial allows variable fan speeds.
0―Fan off
1―Low speed
2―Medium low speed
3―Medium high speed
4―High speed
Interior Comfort
Climate Control System
6-5
