Specifications
qEngine
Item Specification
Type DOHC-16V in-line, 4-cylinder
Bore × Stroke 78.0 × 78.4 mm (3.07 × 3.09 in)
Displacement 1,498 ml (1,498 cc, 91.4 cu in)
Compression ratio 10.0
qElectrical System
Item Classification
Battery 12V-50Ah/20HR, 12V-65Ah/20HR
Spark-plug number Mazda Genuine spark plug ZJY6-18-110, Z6B7-18-110
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particulate
coating on the iridium alloy and pla tinum tips could be damaged.
qLubricant Quality
Lubricant type and classification
Engine oil Refer to Recommended Oil on page 8-13.
Manual transaxle oil
API Service GL-4
SAE 75W-80
Automatic transaxle fluid Mazda Genuine ATF M-V
Brake/Clutch fluid SAE J1703 or FMVSS116 DOT-3
NOTE
Refer to Introduction on (page 8-2) for owner's responsibility in protecting your investment.
