If you are unsure of how tight the nuts
should be, have them inspected at an
Authorized Mazda Dealer.
Nut tightening torque
N·m (kgf·m, ft·lbf) 88―118 (9―12, 65―87)
WARNING
Always securely and cor rectly tighten
the lug nuts:
Improperly or loosely tightened lug
nuts are dangerous. The wheel could
wobble or come off. Thi s could result
in loss of vehicle control and cause a
serious accident.
Be sure to reinstall the sam e nuts you
removed or replace them with metric
nuts of the same configuration:
Because the wheel studs and lug nuts
on your Mazda have metric threads,
using a non-metric nut is dangerous.
On a metric stud, it would not secure
the wheel and would damage the
stud, which could cause the wheel to
slip off and cause an accident.
5. Remove the luggage compartment
cover. Refer to Luggage Compartmen t
on page 3-13.
6. Remove the belt for securing the flat
tire.
7. Return the rear seatback to its original
position. Refer to Split-Folding Rear
Seatback on page 2-5.
8. Remove the tire blocks and store the
tools and jack.
9. Remove the center cap by tapping it
with the lug wrench.
10. Thread the belt through the rear seat
as shown in the figure.
7-12
In Case of an Emergency
Flat Tire
