DESCRIPTION
FUSE
RATING
PROTECTED COMPONENT
18 ENG INJ 15 A Engine control system
19 ENG INJ2 ――
20 H/L HI RH ――
21 H/L HI LH ――
22 DCDC3 ――
23 H/L LO RH 15 A Headlight (RH)
24 H/L LO LH 15 A Headlight (LH)
25 AUDIO2 ――
26 DSC-V2 ――
27 HORN2 ――
28 METER ――
29 ROOM 15 A Overhead light
30 GLOW ――
31 EVVT ――
32 IG KEY 1 40 A For protection of various circuits
33 FAN 3 ――
34 FAN 2 30 A Cooling fan
35 FAN 1 ――
36 INJ ――
37 IG KEY 2 30 A For protection of various circuits
38
――
39
ABS
DSC-P2
――
40 BLOWER 30 A Air conditioner
Maintenance and Care
Owner Maintenance
8-43
