2-6
Essential Safety Equipment
Seats
Form No. 8R21-EA-02G
â–¼
Seat Tilt (Driver’s Seat)
(Manually operated seats)
The seat-bottom angle can be adjusted by
rotating the dial.
(Electrically operated seats)
Front height adjustment
To adjust the front height of the seat-
bottom, raise or lower the front of the
slide lifter switch on the left side of the
seat.
Rear height adjustment
Raise or lower the back of the switch to
adjust the rear height of the seat-bottom.
Up
Down
Dial
Front of seat bottom
Up
Down
Dial
Rear of seat bottom
J16L_8R21-EA-02G.book Page 6 Saturday, June 8, 2002 11:16 AM
