Mazda 2003 Tribute - Page 161

Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box Description
INJ 30A** EEC (VPWR), EVR, MAF, IAC, Bulkhead,
HEGO fuse
MAIN 120A Main
ALT 15A* Alternator/ Regulator
(DRL) 15A* Daytime Running Lamps (DRL) unit
(feed), DRL relay
(DRL2)
(HLEV)
15A*(DRL2)
10A(HLEV)
DRL module, HLEV
PWR 1 15A* Auxiliary power point
FOG 20A* Foglamps, Foglamp indicator
A/C 15A* A/C clutch
(ABS) 25A* Anti-Lock Brake System (ABS) SOL,
EVAC & FILL
PWR 2 15A* Auxiliary power point
IG MAIN 40A** Starter
HTR 40A** Blower motor, Blower motor relay
BTN 1 40A** JB - Accessory relay, Radio, TNS relay,
Cigar lighter, Cluster, Power mirror, GEM,
Accessory delay relay, Power windows,
Power moonroof
(ABS) 60A** ABS motor, EVAC & FILL
BTN 2 40A** JB - Radio, CD changer, Cluster, Dome
lamps, Map lamps, Cargo lamps, Horn
relay, GEM, Power locks, Speed control
MAIN FAN 40A**
(2.0 L)
50A(3.0 L)
Main fan
R DEF 30A** Rear defroster
ADD FAN 40A**
(2.0 L)
50A(3.0 L)
Add fan
Roadside Emergencies
161
