Replacing the transmitter battery
Integrated key type
1. Unfold the key (page 3-2).
2. Insert a small screwdriver into the slot
and push the tab to remove the key
from the transmitter.
Tab
3. Insert a small screwdriver into the slot
and gentl y pry open the transmitter.
4. Press the portion of the battery
indicated by A and remove the battery.
A
NOTE
If it is difficult to remove the battery by
pressing with a finger, use a small
screwdriver to press out the battery.
5. Put in the new battery (CR1620 or
equivalent) with the positive pole (
)
facing down.
6. Align the front and back covers and
snap the transmitter shut.
7. Install the key to the transmitter.
Knowing Your Mazda
Doors and Locks
3-7
