Specifications
qEngine
Item Specification
Type DOHC-24V 60°V Duratec 35, 6-cylinder
Bore×Stroke 92.5 × 86.7 mm (3.64 × 3.41 in)
Displacement 3,496 ml (3,496 cc, 213.3 cu in)
Compression ratio 10.3
qElectrical System
Item Classification
Battery 12V-55AH/5HR MF
Spark-plug number ZZJ1-18110
*1
Spark-plug gap 1.29―1.45 mm (0.051―0.057 in)
*1 ex factory
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particulate
coating on the iridium alloy and pla tinum tips could be damaged.
qLubricant Quality
Lubricant Classification
Engine oil Refer to the recommended SAE viscosity numbers on page 8-19.
Automatic transaxle fluid JWS3309
Transfer case oil API Service GL-5 (SAE 75W-140)
Rear differential oil API Service GL-5 (SAE 80W-90)
Power steering fluid ATF M-III, M-V, or equivalent (e.g. Dexron® II)
Brake fluid SAE J1703, or FMVSS116 DOT-3
10-4
Specifications
