Black plate (181,1)
Vent Operation
Center vents
Side vents
qAdjusting the Vents
Directing airflo w
Side Vents
To adjust the direction of airflow, open the
vents and rotate them left and right.
Push
Center Vents
To adjust the direction of airflow, move
the adjustment knob.
Knob
NOTE
When using the air conditioner, mist may come
out from the vents. This is not a sign of trouble
but a result of humid air being suddenly
cooled.
Interior Comfort
Climate Control System
6-3
Mazda3_8X41-EA-07F_Edition1 Page181
Wednesday, April 25 2007 1:5 PM
Form No.8X41-EA-07F
