Replacing a fog light bulbs
í
1. Turn the screw counterclockwise and
remove it and then partially peel back
the mudguard.
2. Disconnect the electrical connector
from the bulb by pressing the tab on
the connector with your finge r and
pulling the connector downward.
3. Turn the socket and bulb assembly to
remove it. Carefully remove the bulb
from its socket in the reflector by
gently pu lling it straight back out of the
socket.
4. Install the new bulb in the reverse order
of removal.
NOTE
l
To replace the bulb, contact an Authorized
Mazda Dealer.
l
If the halogen bulb is accidentally touched,
it should be cleaned with rubbing alcohol
before being used.
l
Use the protective cover and carton for the
replacement bulb to dispose of the old bulb
promptly and out of the reach of children.
Front turn signal lights/Side-marker
lights
Due to the complexity and difficulty of
the procedure, the bulbs should be
replaced by an Authorized Mazda Dealer.
Side turn signal lights
1. Slide the unit as show n in the figure to
remove it.
2. Detach the electrical connector from
the unit by pulling it to the rear.
3. Install the new side turn signal unit in
the reverse order of remo val.
NOTE
Bulb replacement is not possible because it is
built into the unit. Replace the unit.
Maintenance and Care
Owner Maintenance
8-43
í
Some models.
