7. Remove the belt for securing the flat
tire.
8. Return the third-row seatback to its
original position.
Refer to Fold the Third-Row Seat on
page 2-14.
9. Remove the tire blocks and store the
tools and jack.
10. Place the flat tire in the cargo sub-
compartment.
11. Thread the belt through the wheel as
shown in the figure, then attach the
belt clip s to the attachment loop.
NOTE
Attach location *1 of the belt to the attachment
loop on the right.
Buckle
Belt clips
1
12. Pull the belt end to secure the flat tire.
In Case of an Emergency
Flat Tire
7-13
