Rear turn signal lights, Rear side-
marker light
1. Turn the bolts counterclockwise and
remove them.
2. Pull the unit rearward to remove it.
3. Turn the socket and bulb assembly
counterclockwise and remove it.
Rear turn signal lights
Rear side-marker light
4. Disconnect the bulb from the socket.
5. Install the new bulb in the reverse order
of removal.
8-44
Maintenance and Care
Owner Maintenance
