DESCRIPTION
FUSE
RATING
PROTECTED COMPONENT
15 BTN 2 7.5 A For protection of various circuits
16 AT PUMP ――
17
PTC
*1
――
HEATER
*2
40 A Air conditioner
18 INJ 30 A Engine control system
í
19 R.DEF 30 A Rear window defroster
20 IGKEY 2 40 A For protection of various circuits
21 IGKEY 1 40 A For protection of various circuits
22 HORN 15 A Horn
23 STOP 15 A Brake lights
24
10A Engine control system
25 FUEL PUMP 25 A Fuel system
26 ABS 40 A ABS
27 SEAT WARM 20 A Seat warmer
í
28 EHPAS 80 A Power assist steering
29 ―― ―
30 ABS IG 7.5 A ABS
31 SWS 7.5 A Air bag
32 H/L LO RH 15 A Headlight low beam (RH)
33 H/L LO LH 15 A Headlight low beam (LH)
34 ILLUM 7.5 A Instrument panel illumination
35 TAIL 15 A Taillights, Parking lights, License plate lights
36 ENG INJ 15 A Engine control system
37 ENG BAR 15 A Engine control system
38
ENG INJ
*1
15 A Engine control system
ENG BAR 2
*2
20 A Engine control system
39
EHPAS IG
*1
――
ETV
*2
15 A Engine control system
*1 SKYACTIV-G 2.0
*2 MZR 2.0, MZR 2.3 DISI Turbo and MZR 2.5
8-60
Maintenance and Care
í
Some models.
Owner Maintenance
