5. Install the new bulb in the reverse order
of removal.
Brake lights/Taillights/Rear side-
marker lights, Rear turn signal lights
1. Make sure the ignition is switched off,
and the headlight switch is off.
2. Turn the bolts counterclockwise and
remove them.
3. Pull the upper part of the cover around
the clip outward to detach the clip.
Clip
4. Pull the unit rearward to remo ve it.
5. Turn the socket and bulb assembly
counterclockwise and remove it.
6. Disconnect the bulb from the socket.
Brake lights/Taillights/Rear side-
marker lights
8-44
Maintenance and Care
Owner Maintenance
